EkoSun 70
The system is designed on the basis of proven construction solutions. It is a response to the needs of all customers – it is stable, stiff, airtight, and provides very good acoustic and thermal insulation.
Specification
- profile with a construction depth of 81 mm
- glazing with units up to 55 mm
- two anti-burglar latches per sash
0.89
Uw for Ug = 0.6
(Ultimate spacer)*
1.2
Uw for Ug = 1.1
(Ultimate spacer)**
2
Gaskets
6
Chambers
*The above Uw value is given for a reference window size of 1230 x 1480 mm with 4th/16Ar/4/16Ar/4th (44 mm) glass.
**The above Uw value is given for a reference window size of 1230 x 1480 mm with 4/16Ar/4th (24 mm) glass.
The publication does not constitute a commercial offer. The presented graphic materials are for illustrative purposes only, and the actual colours and textures of the products may differ from those shown in the advertising materials. The graphics presented, including the presentation of colours, cannot constitute the basis for a complaint. Renders show selected profile and glazing sets.
